Automatic butyl extruder

Feature

• PLC control system with touch screen interface
• Numerical control of extruding start and stop time
• Automatic displaying function when out of butyl
• Two heating systems for butyl cylinder and nozzle
• Nozzle height adjustable
• Pre-heating system
• Available for curved spacer extruding
• Nozzle adjust automatically with different spacer width

Technical Data

• Heating temperature：100℃-160℃
• Heating time：30-40min
• Butyl extruding speed：0-30m/min
• Extruding width：4-20mm
• Power：1P+N 220V 50Hz 3kW
• Air pressure：0.7MPa
• Hydraulic pressure：0-20MPa
• Working height：800mm
• Machine size：3000(L)×600(W)×950 (H) mm
